Product Introduction

This 225 kVA Pad mounted transformer was delivered to USA in 2023. The rated power of the transformer is 225 kVA, with the primary voltage 24.94GRDY/14.4 kV to secondary voltage 0.48GrdY/0.277 kV. The connection group is YNyn0, and there are 5 taps ABCDE to adjust the voltage at the primary side, where can output 5 different voltages as wanted.
The 225 kVA Pad mounted transformer is welled design with 98.94% efficiency and our advanced manufacturing process, which may satisfy various voltage requirements.

We ensure that every of our delivered units has undergone full acceptance testing. Our oil immersed power transformer is designed in accordance with CSA, IEEE, ANSI and other major international standards.
