Product Introduction

This 500 KVA power distribution transformer was delivered to Botswana in 2016.The rated power of the transformer is 500 KVA. This 500 KVA step down transformer with 3 phase, and the primary voltage is 11KV, the secondary voltage is 0.4KV, the transformer is equipped with no load tap changer, the tapping range is ±2*2.5% at primary side, the cooling is ONAN, the connect group is Dyn11, our 500 KVA power transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.

We ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Scope of Supply

Product: Oil Immersed distribution Transformer

Rated Power: Up to 5000 KVA

Primary Voltage: Up to 35 KV
