Product Introduction

The rated power of the transformer is 800 KVA, the primary voltage of this is 11KV, the secondary voltage is 6.6KV and 0.4KV, they can be switch to use either of them. The transformer is equipped with 5 tapping position NLTC. Our 800 KVA power transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time. We also provide distribution transformer, dry type transformer, furnace transformer and rectifier transformer. If you interested in any of these items, pls do not hesitate to contact us, we will give you more details.

We ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, our oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Scope of Supply

Product: Oil Immersed distribution Transformer

Rated Power: Up to 5000 KVA

Primary Voltage: Up to 35 KV
