Overview
The contacts of a vacuum circuit breaker are usually made of conductive material and are used to open or close a circuit during switching operation. The functions of the contacts are similar to those in traditional circuit breakers, but using a vacuum circuit breaker can reduce arcing and improve arc extinguishing performance.
Model: AHNG403
Dimension
Technical details
Rated current | 1600A |
Material | Copper/aluminum/Copper and aluminum welding |
Application | vacuum circuit breaker(VS1-12/1600A) |
