Product Introduction

This 2 MVA transformer was delivered to South Africa in 2019. the rated power of the transformer is 2000 KVA. It is a step-down 11 KV to 415V transformer, the primary voltage of the transformer is 11 KV and secondary is 0.4 KV. Our 2 MVA distribution transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.

We ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, our oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Scope of Supply

Product: Oil Immersed distribution Transformer

Rated Power: Up to 5000 KVA

Primary Voltage: Up to 35 KV
