Product Introduction

This 3.5 MVA distribution transformer was delivered to Kenya in 2017, the rated power of the transformer is 3500 KVA. This 3500 KVA Step Down transformer 33kv to 0.4kv, the primary voltage is 33kv, the secondary voltage is 0.4kv. This is an Industrial Power Transformer, which used for factory. The iron core is made of quality cold-rolled silicon steel sheet, and the coil is made of quality oxygen-free copper, featuring good outlook and safe running. Our 3.5 MVA power transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.

We ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Scope of Supply

Product: Oil Immersed distribution Transformer

Rated Power: Up to 5000 KVA

Primary Voltage: Up to 35 KV
