Product Introduction

This 5 MVA power supply transformer was delivered to South Africa in 2013, the rated power of the transformer is 5000 KVA. This 5000 KVA Step Down transformer 33kv to 11kv, the primary voltage is 33kv, the secondary voltage is 11kv. This distribution transformer equipped with OLTC; the cooling is ONAN. Our 5 MVA power transformer was designed with advanced technology and adopts high quality material and components which result in reliable quality and long operation time.

We ensure each one of our delivered transformers had passed the full acceptance test and we remains 0 fault rate record for more than 10 years so far, oil immersed power transformer is designed in accordance with IEC, ANSI and other major international standards.

Scope of Supply

Product: Oil Immersed distribution Transformer

Rated Power: Up to 5000 KVA

Primary Voltage: Up to 35 KV
